Key Part
No. Number Description Qty.
PARTS LIST
1 030155001002 * SCREW (M4 x 16 mm PAN HD.) ..............................................8
2 039066005001 HOUSING TOP .........................................................................1
3 039066005002 LIGHT COVER .........................................................................1
4 039065005017 LIVE TOOL INDICATOR ............................................................1
5 039110006001 SWITCH....................................................................................1
6 039066005004 TRIGGER SWITCH ...................................................................1
7 039066005005 BRUSH ASSEMBLY .................................................................2
8 039065005016 TERMINAL BLOCK ..................................................................1
9 030155001024 * SCREW (M4 x 14 mm PAN HD.) ..............................................2
10 S650D-16 CORD CLAMP ..........................................................................1
11 S650D-02 * SCREW (M4 x 20 mm PAN HD.) ..............................................4
12 039066005009 HOUSING ASSEMBLY .............................................................1
13 S650D-09 BEND RELIEF ...........................................................................1
14 039066005010 POWER CORD ASSEMBLY .....................................................1
15 039066005011 LEAD W/TERMINAL .................................................................1
16 039066005012 ARMATURE ASSEMBLY (INC. KEY NOS. 17 AND 19) ............1
17 039066005013 BALL BEARING (608RZ) ..........................................................1
18 039066005014 FIELD ASSEMBLY ....................................................................1
19 039066005015 BALL BEARING (609-2RS) .......................................................1
20 S650D-22 FAN ...........................................................................................1
21 039066005016 FAN BAFFLE ............................................................................1
22 S650D-25 * SCREW (M4 x 12 mm PAN HD.) ..............................................2
23 030155001010 POST CUSHION.......................................................................2
24 039066005019 PLATEN ASSEMBLY (INC. KEY NOS. 25-32) ..........................1
25 039176001012 BALL BEARING (6000LU) ........................................................1
26 S650D-34 BUMPER ..................................................................................1
27 S650D-29 DUST SHIELD ..........................................................................1
28 S650D-31 * SCREW (M4 x 7.5 mm PAN HD.) .............................................4
29 S650D-32 RETAINING PLATE ...................................................................2
30 039066005021 SPRING CLAMP W/OVERMOLD .............................................2
31 039066005022 PLATEN ....................................................................................1
32 039066005023 PAD ASSEMBLY .......................................................................1
33 039066005026 LOGO LABEL ...........................................................................1
34 039066005027 DATA LABEL .............................................................................1
35 039065005022 DUST BAG ...............................................................................1
36 039176001022 HOLE PUNCH ..........................................................................1
ITEMS NOT SHOWN
37 039066005024 * 60 GRIT SANDPAPER ..............................................................1
38 039066005025 * 80 GRIT SANDPAPER ..............................................................1
39 S650D-42 * 150 GRIT SANDPAPER ............................................................1
40 S650D-43 * 220 GRIT SANDPAPER ............................................................1
41 039066005028 TOOL BAG ...............................................................................1
987000152 OPERATOR’S MANUAL (039066005032)
09-06-07
(REV:00)
* Standard Hardware Item – May Be Purchased Locally
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your SHEET SANDER or when ordering repair parts.
3
RYOBI 1/4 SHEET SANDER - MODEL NUMBER S652D
