Page #15 background imageLoading...
Page #15 background image
4.3 ERROR CODE DESCRIPTION
4.3 ERROR CODE DESCRIPTION
4. VIEWING FAULTS AND
4. VIEWING FAULTS AND
FAULTS CODE DESCRIPTION
FAULTS CODE DESCRIPTION
Error Message Error DescripƟon Level Action taken
Syopnd in travl
Safety circuit and/or door opened during
travel
I
- Waits for safety circuit to close. Calls are cancelled if fault
persists more than 5sec. Waits for call to resume
- In case of VVVF drive: Waits for call to resume
Syopnd in travl Safety circuit opened during travel I
- Waits for safety circuit to close. Calls are cancelled if fault
persists more than 5sec. Waits for call to resume
- In case of VVVF drive: Waits for call to resume
Lock opnd in travl Door lock circuit opened during travel I
- Waits for lock circuit to close. Calls are cancelled if fault
persists more than 5sec. Waits for call to resume
- In case of VVVF drive: Waits for call to resume
Door clsd, not sy
Safety circuit failed to close aer door
closing
I Cancels calls and opens door
Fail to lock cam Failure in locking door aer 3 attempts I Cancels calls
Fail to close door Failure in closing door II Cancels calls, opens door
Sha Info Flt SDFS-UP or SDFS-DN or DZerror II Performs a homing trip
Sha Info Flt SDFS-UP or SDFS-DN or DZerror II Performs a homing trip
No EOS Info EOS-UP and EOS-DN errors (both open) III Blocks elevator
Emergency stop Emergency stop I Waits for a car call to resume
Car is jammed
Motor has been powered for Car jammed
delay, car did not move
I Waits for a car call to resume
Door is obstructed
Door has been opened for more than Door
Obstructed Del
I Waits for door to close
Fail to open door
9
Failure in opening door II Close door and resume
Call Maintenance Preset number of operang days expired III Blocks elevator
Cont.Jam/Sy
Shunt
one contactor or more is jammed or
door/lock contacts are shunted
I
Waits all contactors to be released &/or safety shunt to be
removed.
Motor overheang
Motor temperature has exceeded its
maximum allowable operang temperature
I
Elevator is stopped at the nearest oor. Waits for the motor
to cool down
External err.(VVVF) VVVF external error I
Elevator is stopped. Waits for external VVVF error to be
removed
Uncontrolled Mov
In VVVF, when Door zone is installed, The
li without Up/Down command in Normal
operaon goes out of zone
III Blocks elevator
4
Final Switch Error Final limit switch is reached
II/
III
When the cause of the fault is diagnosed and fixed:
Level 2: The li performs a homing trip.
Level 3: The li is blocked and needs reset.
Wrong dir. Moving Li is moving in the opposite direcon III
Make sure that lift is going in the right direcon, if not switch
up and down direcons outputs. Otherwise, switch encoder
signals
Dist. Counter Fault Incorrect distance counng II Performs a homing trip
No Data from Cabin
CAN bus communicaon between MCI-
DCAN of the Microzed main control and
MCI-DCAN of the Microzed cabin control is
corrupted or interrupted
I
Elevator is stopped at the nearest oor.
MicroZed cabin control will open the door and wait for the
communicaon to be re-established to resume operaon
The last 15 ERRORS are permanently stored along with the time, date of occurrence
and the oor where the error occurred. ERRORS can be accessed through the Select option on LCD Page 4.
Waits for a call to resume operation.
When DZ magnetic switch is installed. Refer to section 5.
When the cause of the fault is diagnosed and xed, the elevator will automatically resume operation.
Relevant in duplex mode only - Refer to section 5.
In case of automatic door, waits for obstacle to clear. For Swinging door, waits for door to close.
To recover from this fault, access menu and clear the count of elapsed days. Refer to sections 5.
For swinging or ½ automatic door.
For automatic door.
Fault level option can be Level 2 / Level 3 if spare input IP3 is congured as Final SW- Refer to section 5.
Thisfault is implemented in version 3.00. Hand above.
