2. TERMINAL DESCRIPTION
2.3 OUTPUT TERMINALS
2.3.1 OUTPUT TERMINALS FOR AC 1 SPEED AND AC 2 SPEED
2.3.1 OUTPUT TERMINALS FOR AC 1 SPEED AND AC 2 SPEED
P
+22
V
Biasing voltage from periphery supply – posive side
GND
Biasing voltage from periphery supply – negative side
LGHT
Car light relay
CLGT
Common for LGHT output
OPN
Open door relay or contactor
CLSE
Cam contactor/ Close relay or contactor
CDOOR
Common for CLSE and OPN outputs
CDRV
Common for DN, UP, HI, LOW and SOP1 outputs
LOW
Low speed contactor
HI
High speed contactor
UP
Up direcon contactor
DN
Down direcon contactor
SOP
1 Spare output 1
SOP
2 Spare output 2
SOP
3 Spare output 3
SOP
4 Spare output 4
2.3.2 OUTPUT TERMINALS FOR VVVF
2.3.2 OUTPUT TERMINALS FOR VVVF
P
+22
V
Biasing voltage from periphery supply – posive side
GND
Biasing voltage from periphery supply – negative side
1
LGHT
Car light relay
CLGT
Common for LGHT output
OPN
Open door relay or contactor
CLSE
Cam contactor/ Close relay or contactor
2
CDOOR
Common for CLSE and OPN outputs
CDRV
Common for DN, UP, HI, LOW and SOP1 outputs
LOW
Low speed contactor
HI
High speed contactor
UP
Forward contactor
DN
Reverse contactor
SOP
1 Spare output 1
SOP
2 Spare output 2
SOP
3 Spare output 3
SOP
4 Spare output 4
2.3.3 OUTPUT TERMINALS FOR HYDRAULIC
2.3.3 OUTPUT TERMINALS FOR HYDRAULIC
P
+22
V
Biasing voltage from periphery supply – posive side
GND
Biasing voltage from periphery supply – negative side
1
LGHT
Car light relay
CLGT
Common for LGHT output
OPN
Open door relay or contactor
CLSE
Cam contactor/ Close relay or contactor
2
CDOOR
Common for CLSE and OPN outputs
CDRV
Common for DN, UP, HI, LOW and SOP1 outputs
LOW
Releveling relay
HI
High speed valve
UP
Pump delta contactor
DN
Down direcon valve
SOP
1 Spare output 1
SOP
2 Spare output 2
SOP
3 Spare output 3
SOP
4 Spare output 4
Although this is not an output, it is listed with the outputs for convenience.
For automatic door only.
For swinging door.
Do not connect for AC 1 speed elevators
