CHARGE PLUS Models CBHF1SM, CBHF1-V2, CBHF2 Page 9 of 12
USERS MANUAL
ONCE THE CHARGE PLUS DISPLAYS THE NAME “SPE”, IT WILL SHOW
THE FOLLOWING IN SEQUENCE.
o SOFTWARE RELEASE/REVISION INSTALLED IN THE
CHARGER.
o BATTERY VOLTAGE.
o CHARGING CURRENT (AMPS).
o CHARGING CURVE NUMBER.
o FINALLY THE WORDS “GEL” OR “Acd” WILL BE DISPLAYED
DEPENDING ON THE SETUP OF THE CHARGER
MAKE SURE THAT THE BATTERY TYPE BEING
CHARGED MATCHES THE BATTERY TYPE DISPLAYED
ON THE SCREEN. IF IT DOESN’T, CONTACT THE
DEALER THAT THE UNIT WAS PURCHASED FROM.
AT THIS POINT, A TEST IS RUN ON THE BATTERY VOLTAGE TO
DECIDE IF THE CHARGING PROCESS SHOULD BE STARTED OR NOT.
IF THE BATTERY IS NOT CONNECTED TO THE CHARGER, THE
DISPLAY WILL SHOW THE WORD “bat”. THIS WORD WILL STAY ON
THE DISPLAY EVEN IF THE TEST HAS FAILED (FOR INSTANCE,
REVERSE POLARITIES OR INCORRECT BATTERY CONNECTION). IF
THE TEST IS PASSED, THE DISPLAY WILL SHOW THE BATTERY
VOLTAGE FOR APPROXIMATELY 5 SECONDS. ONCE THIS TIME HAS
ELAPSED, THE CHARGER WILL BEGIN CHARGING.
THE CHARGE CYCLE PROGRESS WILL BE SHOWN BY RED (3),
YELLOW (4), AND GREEN (5) LED INDICATORS.
WHEN THE CHARGE CYCLE HAS COMPLETED, THE GREEN (5) LED
INDICATOR WILL BE LIT.
FOR CHARGERS PROGRAMMED FOR USE WITH LITHIUM BATERIES
THE USER WILL HAVE NO ACCESS TO CHANGE AMPERAGE OR
VOLTAGE.
