SA LINUS - 12 Technical Data

SAEY LINUS
92.110.240.00 / versie 01 70
English
12 TECHNICAL DATA
Results
LINUS
Power range kW 4 - 10
Nominal power kW 8
Performance % 84
CO-emissions ( at 13% O2) Mg/Nm³ 1129
Particle emissions Mg/Nm³ <20
Fume temperature at nominal power °C 270
Size and weight
Height mm 1050
Diameter mm 450
Outer diameter of flue mm 130
Outer diameter combustion air supply mm 100
Height center combustion air supply mm 148
Rear connection Ja/nee nee
Space to heat ( indicative) M³ Tot 200
Weight Kg 190
Installation values
Hearth draught at nominal power Pa 12
Hearth draught limits Pa 12 - 20
Supply of fresh air M³/h 25
Fuel
Consumption at nominal power Kg 2
Consumption at maximum power Kg 3.6
Maximum humidity % 20
Maximum length horizontal mm 250
Maximum length vertical mm 500
Maximum diameter mm 180
