Parts to be used for door reverse
SN part Quantity Notes
1 Upper hinge 1
Pre-installed on refrigerator,
removed and retained it when
changing the door
2 Upper hinge cover 1
3 Decorative cover 1
4 Door self-locking 2
5 Middle hinge 1
Pre-installed on the refrigerator
and to be used when changing the
door
6 Decorative cover 1
7 Lower hinge 1
8 Levelling feet 1
9 Left upper hinge 1
In the attached plastic bag, take
them out for use when door is
reversed
10 Left upper hinge cover 1
11 Left door self-locking 2
12 Right plastic cover 1
1. Remove all food from the inner door liner.
2. Remove the upper left hinge cover decorative cover, upper right hinge cover
and upper right hinge, and disconnect the right signal line terminal 1 and
signal line terminal 2 at the top of the box body.
3. Remove the refrigerated door body (be careful not to lose small parts such as
the shaft sleeve and stop on the door); Remove the middle hinge and remove
