DESCRIPTION OF THE DEVICE
1. Freezer Shelf
2. Freezer Tempperature Control
3. Control panel
4. Refrigerator Shelves
5. Crisper Cover
NOTE: The appliance design is subject to change without prior
notice�
INSTALLATION
5150
GB GB
Position the appliance and allow it to stand for two to three hours
before it is turned on for the rst time to allow the System to
settle� Do not position next to any heat source e�g� cooker, boiler
or in direct sunlight etc�
Allow at least 10cm of space at the top and 10 cm of space
on both sides of the appliance and between the back of the
appliance and the wall for enough air circulation� The appliance
is not designed for recessed installation (“building in”)�
Install on a good rm level surface, and any unevenness of the
oor should be corrected prior to installation, slight unevenness
can be overcome by adjusting the front feet�
NOTE: If the appliance is positioned on a carpet, soft oor
covering you should readjust the front feet once the appliance
has had time to settle�
W D H A B C(°) E F
545 590 1700 8457 1059 125±5 50 100
Heat dissipation space
When working, the refrigerator gives off heat to surroundings.
Therefore, at least 30mm of free space should be spared at the
top side, more than 100mm on both sides, and above 50mm at
the back side of the refrigerator.
Dimensions in mm:
Note: Figure 1, Figure 2 only illustrate the space demand of the product.
6. Salad Crisper
7. Adjustable Feet
8. Freezer Racks
9. Refrigerator Racks
