Installation
• The manufacturer will not be held
liable for any damages resulting from
incorrect or improper installation�
• The minimum distance between the
supporting surface for the cooking
vessels on the hob and the lowest part
of the range hood� (When the range hood is located above
a gas appliance, this distance shall be at least 65 cm� If the
instructions for installation for the gas hob specify a greater
distance, this has to be taken into account� The distance of 65
cm can be reduced for: non-combustible parts of range hoods,
and parts operating at safety extra low voltage, provided these
parts do not give access to live parts if deformed ;)
• Check that the mains voltage corresponds to that indicated on
the rating plate xed to the hood�
• For Class I appliances, check that the domestic power supply
guarantees adequate earthing�
• Connect the extractor to the exhaust ue through a pipe of
minimum diameter 120mm� The route of the ue must be as
short as possible�
• The air must not be discharged into a ue that is used for
exhausting fumes from appliances burning gas or other fuels�
• If the extractor is used in conjunction with non-electrical
appliances (e�g� gas burning appliances), a sucient degree
of aeration must be guaranteed in the room in order to
22
