Connections
DUCTED VERSION AIR EXHAUST SYSTEM
When installing the ducted version,
connect the hood to the chimney using
either a exible or rigid pipe Φ 150 or
Φ 120 mm, the choice of which is left to
the installer�
• If to install a Φ 120 mm air exhaust connection, insert the
reducer ange 3 on the hood body outlet�
• Fix the pipe 4 in position using pipe clamps (not supplied)�
• Remove possible charcoal lters�
Upper Decorative Chimney
• Insert the upper chimney 2�2 into the lower chimney 2�1 and
drag it up to bracket 21 on the horizontal line C
• Fix the chimney 2�2 at bracket 21 with 2 screws 12�
32
GB
C
