SABAF 10 - Inlet Variants; Outlet Variants

SABAF S.p.A.
Via dei Carpini, 1
25035 Ospitaletto (Brescia) Italia
Model 10, 10P, 10X, 10Y, 10PZ
Revision 06 – set 16
page 4 of 6
INLET VARIANTS
inlet
denomination
assembly
1 – 1N
single bracket
1 screw
tube diameter 14 mm
(hole diameter 8.2 mm)
2 – 2N
single bracket
1 screw
tube diameter 16 mm
(hole diameter 8.2 mm)
5 - 5N
single bracket
1 screw
tube diameter 18 mm
(hole diameter 8.2 mm)
8 – 8N
bracket
2 screws
tube diameter 18 mm
(hole diameter 8.2 mm)
9 – 9N
bracket
2 screws
tube diameter 1/2"gas
(hole diameter 8.2 mm)
13 – 13N
bracket
2 screws
tube diameter 16 mm
(hole diameter 8.2 mm)
14
flange
2 screws
flat tube
(hole diameter 5.7 mm)
15 – 15N
bracket
2 screws
tube diameter 8 mm
(hole diameter 5.7 mm)
16 – 16N
bracket
2 screws
tube diameter 10 mm
(hole diameter 5.7 mm)
17 – 17N
bracket
2 screws
tube diameter 14 mm
(hole diameter 8.2 mm)
19 – 19N
bracket
2 screws
tube diameter 19 mm
(hole diameter 8.2 mm)
20 – 20N
bracket
2 screws
tube diameter 17 mm
(hole diameter 8.2 mm)
27 – 27N
single bracket
1 screw
tube diameter 16 mm
(hole diameter 8.2 mm)
OUTLET VARIANTS
outlet
denomination
assembly
A
injector
injector + external thread
B
injector
injector
C
tube diameter 8 mm
compression fitting
D
tube diameter 6 mm
compression fitting
E
G 1/4”
flared tube
F
M 140 x 1.5
flared tube
G
tube diameter 7 mm
compression fitting
H
M 16 x 1.5
flared tube
I
tube diameter 6 mm
compression fitting
K
tube diameter 4 mm
compression fitting
J
injector
injector
L
tube diameter 7 mm
compression fitting
M
tube diameter 8 mm
compression fitting
N
tube diameter 10 mm
compression fitting
O
tube diameter 6.35 mm
compression fitting
P
tube diameter 6 mm
compression fitting
Q
tube diameter 6.35 mm
compression fitting
R
injector
injector
S
tube diameter 6 mm
compression fitting
T
tube diameter 8 mm
compression fitting
U
tube diameter 8 mm
compression fitting
V
G 1/8”
various
W
M 16 x 1.25
flared tube
Y
tube diameter 7 mm
compression fitting
X
Gc 1/8” angle 6°
various
Z
tube diameter 8 mm
compression fitting
