Setting Introduction
SABAJ A20d
INPUT
PCM FILTER
I
2
S MODE
BRIGHTNESS
IN1 BLUETHOOTH
IN2 USB
IN3 OPTICAL
IN4 COAXIAL
Nor (Normal)
INV (Inverted)
bL1 ~ bL3 (Brightness level)
IN5 I
2
S
FL1 (Fast Roll-off linear phase)
FL2 (Slow Roll-off linear phase)
FL5 (Apodizing, fast roll-off, linear phase)
FL3 (Fast Roll-off minimum phase)
FL4 (Slow Roll-off minimum phase)
FL6 (Hybrid, fast roll-off, minimum phase)
FL7 (Brickwall filter)
DPLL
I
2
S DSD CHANNEL
L-r (Normal)
r-L (L/R exchange)
I
2
S DSD FLAG
P15 (Pin15 for DSD indicator)
P14 (Pin14 for DSD indicator)
dPL 1~15, Lower for Better De-jitter
