1/380175-168 - ENG
Rev. 2005.09
Operating Manual - SAB 202
Manual for SAB 202
The screw compressor and the unit may be fitted
with different equipment, depending on their func-
tions and requirements.
Part of this equipment is described in this manual
although it may not be fitted on your particular
unit.
In the table, the x mark indicates which equipment
is fitted on your particular unit with the compressor
number stated below.
Compressor
SM ❏ LM ❏ SF ❏ LF ❏
Compressor no.
Refrigerant
❏ R717 ❏ HFC/HCFC: ______ ❏ Other: ______
Control
Transducers and manual regulation of Vi slide
UNISAB II and manual regulation of Vi slide
UNISAB II and automatic regulation of Vi slide
Oil filter
Internal
External
Oil cooling
Water cooled oil cooler
❏ OWRF ❏ OWTF
Other: ______
Refrigerant cooled oil cooler OOSI
Refrigerant injection in compressor
❏ HLI ❏ BLI
Oil separator
With 1 discharge valve
With 2 discharge valves
Oil temp.reg. Thermostatic oil valve
Economizer
system
(ECO-system)
With vessel type HESS
With closed system and vessel type EOSE
With open system and vessel type SVER
Ex-execution
Compressor and unit are safeguarded
