Forced mode. I
max
=2000mA. DIP switches S1, S2, and S3 are ignored.
LED3 color will be blue or green depending on the position of S1.
↓ — DIP switch position DOWN, ↑ — DIP switch position UP, × — any position
Recommended modes
Mode Nr. 1 or 5
*
(Auto or Manual PoE mode. I
max
= auto or I
max
=1700mA);
*
depending on HW revision
Electrical specification
Data rate
Up to 1000 Mb/s
Auto PoE mode
Green indicator LED*
Manual PoE mode
Blue indicator LED*
Input Voltage
22 – 65 V
Output Voltage
54 V
Max Current
1.2 A (22…36V DC), 1.6 A (36…60V DC)
Power Connector
2ESDV-02P with screw locks
Ethernet Connectors
Shielded RJ45 jacks
Data Lines
Pins (1, 2), (3, 6), (4, 5) and (7, 8)
Power Lines
+ (1, 2) and (4, 5); - (3, 6) and (7, 8)
Power Clamping Voltage
+/- 70 V
Max data cable length
100 m
* Color indication can be disregarded in Forced mode (DIP S4 position DOWN), will indicate only Power ON.
Mechanical specification
Ports
- -RJ45 - Data
- -RJ45 - Data + Power
- -DC - 2ESDV-02P socket with screw locks**
- -Grounding screw
Dimensions (W/H/D):
- 82 mm/41 mm/154 mm
Weight
- 0.4 kg
Enclosure
- Steel
Operating Temperature
- -10ºC to + 50ºC
Mounting
-With bracket (included)
-19” rack mounting shelf (p/n
I0KTPI11.003)
-DIN-rail clip (p/n I0STPI11.01)
** 2ESDV-02P plug with screw locks included.
System requirements
To access the Integra/Integra-S/Integra-G/Integra-GS Web GUI you will need a PC with the
following Web browser:
• Google Chrome;
• Mozilla Firefox;
• Internet Explorer 8 (or above)
