INTEGRA/-S/-G/-GS User Manual WEB GUI
SAF Tehnika JSC
41
ACM (Adaptive Coding and Modulation) for further details) enables adaptive
modulation change according to MSE value. Modulation indicates maximum
modulation, while the minimum is 4QAM.
In case the current Tx power value is above the maximum value for any of the
modulations, the maximum value will be indicated.
14) By pressing „Execute configuration”, changes made to the corresponding section
apply only to the local side Integra/Integra-S/Integra-G/Integra-GS. If „Rollback on” is
selected, the configuration will be reverted in case erroneous configuration changes
are applied.
Pressing „Execute for both” applies changes made to the corresponding section both
for local and remote side Integra/Integra-S/Integra-G/Integra-GS FODUs.
CLI commands (Chapter 4: COMMAND LINE INTERFACE)
radio [status]
Use to show radio status.
radio power <Tx power>
Use to set Tx power in dBm.
radio frequency <frequency>
Use to set Tx frequency in kHz.
radio rssi-led {disable | enable
[mode {1|2|3}]}
Use to enable or disable RSSI LED operation.
radio rssi-led enable mode
{1|2|3} polarization <seconds>
Use to enable the red RSSI LED's operation for n seconds.
Its main purpose is an indication of polarization alignment
accuracy +/- 3deg. Functionality may not be available in
older HW revisions.
radio tx-mute {<time>|disable}
Use to mute the transmitter to a specific time in seconds
or unmute.
radio factory
Use to reset radio settings to factory defaults – Tx power
will be disabled and frequencies set to factory defaults.
radio upgrade <firmware>
Use to upgrade the radio firmware version. The firmware
file must be located in the FTP directory.
radio version
Use to check the radio software version
radio atpc [status]
Use to check the status of ATPC (Automatic Transmit
Power Control).
radio atpc state
{enable|disable}
Use to enable/disable ATPC.
radio atpc delay <1..5>
Use to define the ATPC update period.
radio atpc rx_level <-75..-43> <-
72..-40>
Use to define ATPC remote Rx level min and max
thresholds.
modem configuration set
<bandwidth> <min_mod>
<max_mod>
Use to set modem configuration – bandwidth, minimum
and maximum modulation.
“e” suffix indicates “AES”.
