8 states are possible – Master, Slave, Active (transition to Passive, Slave, or Active
Try), Passive (transition to Slave), Active Try (1+1 transition to Active Tx), Active Tx
(1+1 transmitting), Standby (ready for 1+1 protection), and TpDown (Slave state when
Traffic port is down). In the case of TpDown aggregation port (LAN2) is shut down as
well.
7) Instance ID (0…65535) – Indicates configured instance ID (status mode); allows
entering instance ID (modify mode). Will be available only when Master protection is
enabled.
Instance ID should be the same on all 4 devices in a single link.
Instance ID should differ for other 2+0 links in the network.
8) Ethernet traffic port – Indicates which LAN port is configured as the
traffic/management port (status mode); allows setting LAN1 or LAN3 port as the
traffic/management port (modify mode).
Alarms
9) Indicates which alarms are active. If none, “None” is shown.
Aggregation port link is down – the link status of the aggregation port (LAN2) of
the local device is down.
AIS condition – synchronization loss of Master or Slave device or link status of
aggregation port (LAN2) of the remote device is down.
Master protection data
The status of all four units is shown. Local – the unit you are currently connected to;
alternative – unit interconnected with the local unit; remote – unit on the remote side of the
link synchronized to the local unit; remote alternate – unit interconnected with the remote
unit.
The section is visible when aggregation is enabled.
If no data is available “N/D” will be displayed in red color.
10) Reset timeout – Allows resetting protection data refresh time counters. The button is
available only in modify mode.
11) Configured role – Indicates configured role;
12) Current role – Indicates current role. May differ from the configured role in case
Master protection is enabled, the alternate device is or was not available and
reconfiguration to 1+0 configuration took place;
13) Timeout max – Maximum refresh time of protection data in milliseconds;
14) Timeout last – Most recent refresh time of protection data in milliseconds;
15) Index – Aggregation data identifier. Value sequentially increments to 65535 and
resets to 0;
16) Instance ID – Indicates configured instance ID;
17) FSM state – Indicates current Finite State Machine’s state. Will be visible only when
Master protection is enabled.
18) LAN1 – Indicates link status of LAN1 port – up or down;
19) LAN2 – Indicates link status of LAN2 port – up or down;
20) LAN3 – Indicates link status of LAN3 port – up or down;
21) WAN – Indicates link status of WAN port – up or down;
22) MNG – Indicates link status of MNG port – up or down;
