Car lift installation, operation and maintenance manual Type：4SF-4000C
9
Main column 1 pieces (with motor board) Secondary column 2 pieces Secondary column A 1 pieces
<6>:Take out: A: beam 2, B: insurance mechanism is connected with the 1 sets of C components before and after blocking 4, D: 4 E: dashboard
baffle, baffle tire 4, F mobile component 4, put it in a free place
Beam 2 pieces Before and after blocking 4 pieces
Dashboard 4 pieces Block the tyre bracket 4 pieces
Moving components 4 pieces
<7>.
The demolition of the bridge plate and side packing frame screws, remove the packing frame, crane for bridge side away, moved to the vacant
To Next Page
