SAGEMCOM F@ST 5302 - Connection

5
F@ST 5302
Connection
Connecting your router
Make the connections as shown in the diagram below.
RJ11
RJ11
Line
wall socket
Phone set
Mains Adapter
with its lead
Mains
wall socket
Power
Reset
WLAN
USB
LAN1
LAN2
LAN3
LAN4
Phone
DSL
WPS
PWR
RJ11
PHONE
Filter/Spitter
LINE
Line
wall socket
PSTN
line
Phone set
OR
If phone line isn't VoIP (Voice over Internet Protocole)
