Specications
Maximum cylinder volume (US gal)
Mean thermal capacity (BTU/hr)
power consumption (W)
Operating current (a)
Voltage (v) / frequency (Hz)
Operating temperature range (ºF)
Refrigerant uid and charge (Ibs)
Max. Hot water temperature (ºF)
BMTB weight unlled/lled (lbs)
Dimensions (height x width x depth(“)
Clearances Top/front (“)
Max water circuit working pressure (psi)
Cold water input connections (“)
Hot water output connections (“)
Single panel weight (Ibs)
Single panel dimensions (h x w x d ”)
Double panel weight (Ibs)
Double panel dimensions (h x w x d ”)
Thermodynamic panel input / output
Lubricant in the compressor
Sound Power Level
R134a Global Warming potential
3.8
BMTB 300
79
2580-6800
Typically 600
4-5
220 - 240, 50/60
32-105
R134a / 2.64
130
322/983
84.6 x 25.6 x 25.6
4/15
45
3/4
3/4
17.64
66.9 x 31.5 x 1
33.06
66.9 x 31.5 x 4
3/8 / 3/8
ESTER / IOSS
41Db(A)
(GWP) 1430
BMTB 130
34
2580-6800
Typically 600
4-5
220-240, 50/60
32-105
R134a / 2.64
130
183/470
50.8 x 21.7 x 21.7
4/15
45
3/4
3/4
17.64
66.9 x 31.5 x 1
33.06
66.9 x 31.5 x 4
3/8 / 3/8
ESTER / IOSS
41Db(A)
(GWP) 1430
BMTB 200
52
2580-6800
Typically 600
4-5
220-240, 50/60
32-105
R134a / 2.64
130
234/675
66.1 x 23.6 x 23.6
4/15
45
3/4
3/4
17.64
66.9 x 31.5 x 1
33.06
66.9 x 31.5 x 4
3/8 / 3/8
ESTER / IOSS
41Db(A)
(GWP) 1430
