SAHP BMTB 130 - Page 9

SAHP - BMTB Installation Manual |9
V1 Mar 2019US - SD667052
SECTION 4
PLUMBING
INSTALLATION continued
!
4.8
A
B
C
D
E
F
G
H
I J
K
L
M
N
O P Q R
S
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
Thermodynamic evaporator panel
Big Magic Thermodynamic Box
Hot water outlet
Pressure & temperature relief valve
Dual thermostat
Sensor pocket
Boiler ow
Immersion heater
Boiler return
Cold water in
Drain
Tundish
Pressure relief valve
Expansion tank
One way valve
Pressure reducing valve
Isolating valve
Cold main
Isolating valve
Fig
