2.2 Turning all zones ON or OFF *
1. Press ZONE or or until the global screen is displayed.
2. Press to turn all zones on or off as required.
General system information scrolls across the bottom line of the LCD when the system is on.
E.g. Fan=80% Cooling =60% Mode=Auto
2.3 Selecting the Conditioning Mode *
The mode of operation for the main air conditioning plant can be selected from global screen of the LCD
touchpads. The global screen can be identified by general system information scrolling across the bottom line
of the LCD.
E.g. Fan=80% Cooling =60% Mode=Auto
Auto – selects heat or cool as required
Heat – Heating only
Cool – Cooling only
Vent – Fan only – no heating or cooling
1. Press MODE to access the mode selection screen.
2. Use or to alter the mode.
3. Press SET and save and exit.
2.4 Selecting the Zone Mode *
The mode of operation for individual zones can be selected from each zone screen of the LCD touchpads. The
zone screen can be identified by the actual zone name being displayed.
E.g.
Temp Set – selects damper modulates to maintain target temperature
MotorSet – provides manual damper positioning in 5% steps regardless of room temperature.
1. Press MODE to access the mode selection screen.
2. Use or to alter the mode.
3. Press SET to save and exit.
2.5 Viewing a zones status *
1. Press ZONE or or to cycle from the global screen through each of the individual zone status
screens.
2. The current status of the selected zone is displayed on the second line of the LCD readout. If the
zone is on the zone status scrolls across the bottom of the display.
E.g. Setpoint=22.5°C, Temp=23°C
