Operating instructions Concept PDG 2906 peristaltic dosing pump
33 / 44
“Detergent dosing” menu
Detergent dosing
Input
Predosing time
Column 1: (Del.) Predosing delay
Time from starting to fill the washing tank until
predosing start
Column 2: (Dt.) Predosing time (= Dosing time
while the washing tank is being filled)
Input 0
Conductivity
Input 0 applies to Concept PDG 2906
Important: A value must be entered for input 0
Input 1 applies to additional pump 1
Input 2 applies to additional pump 2
Line 1: : Display actual conductivity value
Line 2: x: Input conductivity setpoint value
Input 1
Conductivity
Input 2
Conductivity
Input
Dosing alarm time
Time from start of dosing until the setpoint is
reached in the washing tank. If the setpoint
value is not reached within this time, the alarm
sounds.
Input
Predosing time
Column 1: (Del.) Predosing delay
Time from starting to fill the washing tank until
predosing start
Column 2: (Dt.) Predosing time (= Dosing time
while the washing tank is being filled)
“Rinse-aid dosing” menu
Rinse-aid dosing
Input 0
Dosing
Constant dosing: ml/h
Setting range: 5 … 500 ml/h
Variable dosing:: ml/litre fresh water
Setting range: 0.05 … 5 ml/litre
Input 1
Dosing
Input 2
Dosing
