What to do if the DSC operation is not working on my Sailor Transceiver?
The DSC operation requires the MMSI number to be entered into the VHF radio. This is necessary for the DSC function to work. Refer to Entering the MMSI number on page 3-2 for further details.
Why GPS is not working on my Sailor Transceiver?
The automated GPS update may be lost due to missing data, broken cabling, or a failure of the GPS/position source. Refer to the installation section in the back of this manual for installation and connection details. Until the automatic position update from GPS/position source is restored position and time must be entered manually when prompted by a (four hour) timer in VHF. You can verify the position data in the DSC SETUP, Position Info. If data is present Lat/Lon/UTC will be displayed.
How to fix Sailor Transceiver that will not turn on?
Check if power is present. Also, inspect the fuse located in the power connector. If connected to a power supply, verify its performance.
General| Waterproof Rating | IPx8 |
|---|---|
| Display | LCD |
| GPS Interface | NMEA 0183 |
| Temperature Range | -15°C to +55°C |
| Output Power | 25 W / 1 W |
| Channels | International channels |
Introduction to the SAILOR 6222 VHF DSC, its features, and approvals.
Detailed identification and description of all controls on the front panel of the VHF radio.
Explanation of the various fields, icons, and information displayed on the VHF radio screen.
List and description of accessories compatible with the SAILOR 6222 VHF DSC.
Procedures for unpacking the equipment and performing an initial inspection for damage or completeness.
Guidelines for mounting the VHF radio as desktop, overhead, or flush-mounted unit.
Step-by-step instructions for flush mounting the VHF radio into a panel.
Details for installing the SAILOR 6090 Power Converter, including dimensions and connections.
Description of all connectors on the VHF radio, including front and rear panel interfaces.
Guidelines for installing VHF and DSC antennas, including cable requirements and positioning.
Overview of available accessories and their part numbers for the VHF DSC system.
Covers powering on/off, volume adjustment, and navigating menus for basic use.
Procedure for entering the vessel's MMSI number, critical for DSC functionality.
Information on contacting support and performing general maintenance tasks like cleaning.
Guide to diagnosing and resolving common operational problems, symptoms, and remedies.
Instructions for replacing blown fuses in the power connector and the power converter.
Details regarding product warranty, returning units for repair, and proper repacking.
Detailed technical data for the SAILOR 6222 VHF DSC transceiver unit.
General specifications related to the Digital Selective Calling (DSC) capabilities.
NMEA data rates/formats and specifications for the SAILOR 6090 Power Converter.
A list of various examples showcasing system configurations with different components.
Examples of connecting SAILOR 6090 Power Converter, N163S AC, and N420 DC Power Supplies.
Examples of integrating GPS, loudspeakers, alarms, handsets, and microphones into the system.
Various examples of CAN bus configurations with SAILOR 6204 CSMs at different distances and arrangements.
Instructions for installing LAN connections and configuring printers for DSC message printing.
