7 PARTSLIST RM2042
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
R79-3 RESISTOR SMD 0805 1k0 OHM 5% 0.1W ROHM MCR 10 EZH J 102 302.048
R80-3 RESISTOR SMD 0805 100 OHM 5% 0.1W ROHM MCR 10 EZH J 101 302.036
R81-3 RESISTOR SMD 0805 2k7 OHM 5% 0.1W ROHM MCR 10 EZH J 272 302.053
R82-3 RESISTOR SMD 0805 2k7 OHM 5% 0.1W ROHM MCR 10 EZH J 272 302.053
R83-3 RESISTOR SMD 0805 100 OHM 5% 0.1W ROHM MCR 10 EZH J 101 302.036
R84-3 RESISTOR SMD 0805 1k0 OHM 5% 0.1W ROHM MCR 10 EZH J 102 302.048
R85-3 RESISTOR SMD 0805 5R6 OHM 5% 0.1W ROHM MCR 10 EZH J 5R6 302.021
R86-3 RESISTOR SMD 0805 680 OHM 5% 0.1W ROHM MCR 10 EZH J 681 302.046
R87-3 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 EZH J 104 302.072
R88-3 RESISTOR SMD 0805 270k OHM 5% 0.1W ROHM MCR 10 EZH J 274 302.077
R89-3 RESISTOR SMD 0805 2k2 OHM 5% 0.1W ROHM MCR 10 EZH J 222 302.052
R90-3 RESISTOR SMD 0805 2k2 OHM 5% 0.1W ROHM MCR 10 EZH J 222 302.052
R91-3 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 EZH J 104 302.072
R92-3 RESISTOR SMD 0805 27k OHM 5% 0.1W ROHM MCR 10 EZH J 273 302.065
R93-3 PRESET SEALED 50k OHM 25% 0.1W BOURNS 3374X-1-503-E (G) 310.450
R94-3 RESISTOR SMD 0805 22k OHM 5% 0.1W ROHM MCR 10 EZH J 223 302.064
R95-3 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 EZH J 104 302.072
R96-3 RESISTOR SMD 0805 270k OHM 5% 0.1W ROHM MCR 10 EZH J 274 302.077
R97-3 RESISTOR SMD 0805 47k OHM 5% 0.1W ROHM MCR 10 EZH J 473 302.068
R98-3 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R99-3 RESISTOR SMD 0805 470k OHM 5% 0.1W ROHM MCR 10 EZH J 474 302.080
R100-3 RESISTOR SMD 0805 820 OHM 5% 0.1W ROHM MCR 10 EZH J 821 302.047
R101-3 RESISTOR SMD 0805 47 OHM 5% 0.1W ROHM MCR 10 EZH J 47R 302.032
R102-3 RESISTOR SMD 0805 11k5 OHM 1% 50mW PHILIPS 2322 734 2/61153 302.476
R103-3 RESISTOR SMD 0805 36k5 OHM 1% 50mW PHILIPS 2322 734 2/63653 302.524
R104-3 RESISTOR SMD 0805 9k53 OHM 1% 50mW PHILIPS 2322 734 2/69532 302.464
R105-3 RESISTOR SMD 0805 121k OHM 1% 50mW PHILIPS 2322 734 2/61214 302.578
R106-3 RESISTOR SMD 0805 4k53 OHM 1% 50mW PHILIPS 2322 734 2/64532 302.433
R107-3 RESISTOR SMD 0805 487k OHM 1% 50mW PHILIPS 2322 734 2/64874 302.636
R108-3 RESISTOR SMD 0805 100k OHM 1% 50mW PHILIPS 2322 734 2/61004 302.570
R109-3 RESISTOR SMD 0805 205k OHM 1% 50mW PHILIPS 2322 734 2/62054 302.600
R110-3 RESISTOR SMD 0805 30k1 OHM 1% 50mW PHILIPS 2322 734 2/63013 302.516
R111-3 RESISTOR SMD 0805 487k OHM 1% 50mW PHILIPS 2322 734 2/64874 302.636
R112-3 RESISTOR SMD 0805 27k OHM 5% 0.1W ROHM MCR 10 EZH J 273 302.065
R113-3 RESISTOR SMD 0805 1k0 OHM 5% 0.1W ROHM MCR 10 EZH J 102 302.048
R114-3 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R115-3 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R116-3 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R117-3 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R118-3 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 EZH J 104 302.072
R119-3 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 EZH J 104 302.072
R120-3 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 EZH J 104 302.072
R121-3 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 EZH J 104 302.072
R122-3 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R123-3 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R124-3 PRESET SEALED 50k OHM 25% 0.1W BOURNS 3374X-1-503-E (G) 310.450
R125-3 RESISTOR SMD 0805 120k OHM 5% 0.1W ROHM MCR 10 EZH J 124 302.073
R126-3 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 EZH J 104 302.072
R127-3 RESISTOR SMD 0805 100 OHM 5% 0.1W ROHM MCR 10 EZH J 101 302.036
R128-3 RESISTOR SMD 0805 680 OHM 5% 0.1W ROHM MCR 10 EZH J 681 302.046
R129-3 RESISTOR SMD 0805 3k9 OHM 5% 0.1W ROHM MCR 10 EZH J 392 302.055
R130-3 RESISTOR SMD 0805 2k2 OHM 5% 0.1W ROHM MCR 10 EZH J 222 302.052
R131-3 RESISTOR SMD 0805 2k2 OHM 5% 0.1W ROHM MCR 10 EZH J 222 302.052
R132-3 RESISTOR SMD 0805 27k OHM 5% 0.1W ROHM MCR 10 EZH J 273 302.065
R133-3 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 EZH J 104 302.072
R134-3 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 EZH J 104 302.072
R135-3 RESISTOR SMD 0805 100 OHM 5% 0.1W ROHM MCR 10 EZH J 101 302.036
TR1-3 TRAFO 157MHz ADJUSTABLE SUMIDA ELEC.CO. S-7GD / 0237-1756 38.430
TR2-3 TRAFO RF 2u7H ADJUSTABLE TOKO F292MNS-3342BQE 38.431
U1-3 NBFM IF SYSTEM MC3372 MOTOROLA MC3372D 350.570
U2-3 1200 bps FSK MODEM MSM6927 OKI MSM6927GS-K 356.620
U3-3 QUAD OP.AMP. LM324 MOTOROLA LM324D R2 350.530
U4-3 QUAD COMPARATOR LOW POW. SO14, LM339 LM239 TEXAS LM339DR (LM239DR) 350.540
U5-3 INTEGRATED CIRCUIT 74HC132D TEXAS* #SN74HC132DR 355.231
U6-3 TRIPLE 2-CHANNEL ANALOG MULTIPLEXER, 74HC4053 PHILIPS 74HC4053D 355.313
U7-3 QUAD OP.AMP. LM324 MOTOROLA LM324D R2 350.530
U8-3 QUAD OP.AMP. LM324 MOTOROLA LM324D R2 350.530
U9-3 QUAD 2-INPUT NOR GATE HCMOS 74HC02 MOTOROLA MC74HC02DR2 350.202
U10-3 VOLTAGE REG. ADJUSTABLE Io=100mA LP2951C NATIONAL LP2951CM (LP2951ACM) 350.050
U11-3 VOLTAGE REGULATOR 5V/0.1A 78L05A MOTOROLA MC78L05ACD R2 350.100
X1-3 CRYSTAL C1074 14.850MHz 10ppm NC18C DANTRONIC ECI SPEC: C1074 39.839
X2-3 CRYSTAL 3.579545MHz 50ppm NDK LN-P-0002-3.579545MHz 39.767
X3-3 CRYSTAL OVERTONE 141.225MHz 10ppm HC43/U DANTRONIC SP SPEC: C1099A 39.842
XR1-3 CERAMIC RESONATOR Fr = 450kHz MURATA CDBM450C7 41.507
9716
PAGE 7-10
