97-147768-A SAILOR 6300B MF/HF Service Interface User Manual
12
3.2.2 CONFIG
The CONFIG tab contains two side-bar buttons and each are described in turn:
Figure 9: CONFIG tab – Configuration side-bar page.
Enter or change the MMSI number of the radio.
allocated you can use the 9-digit MMSI or leave the field empty.
This is used for Telex identification and is part of the answer
back string. The abbreviated ID is usually 4 ASCII letters, e.g.
‘abcd’.
delay used during Telex ARQ calls.
elect this tag if the system
Tuning Unit) connected. The option is used for dedicated
antenna on specific frequency or dummy load.
Note: Wrong selection may damage the ATU.
If the radio’s power supply is a SAILOR 6081 you can enable the
Power Supply Monitor in the radio.
Select this tag if you want this radio to have priority over a
duplicate MF/HF installation.
