Technical Specification
Electrical
Channel Capability GMDSS sets have simplex channels only - 06, 08-17,
67-69, 71-74, 77
Frequency Range 155-163Mhz
Operating Temperature Range -20°C - +60°C
Output Power 1 & 2.5W
Harmonic and Spurious Emissions <.25µW Tx, <1nW Rx
Sensitivity 0.5µV for 20 dB SINAD
Selectivity 70 dB (±25 kHz)
Intermodulation 70 dB
Channel Spacing 25kHz
Blocking 90dB
Spurious Response 70dB
Audio Output Power Max 0.4W
Current Consumption Squelched <25mA
Receive typically 125mA
Transmit 2.5W 0.95A
1W 0.6A
Weight 400g including battery pack
Environmental
Waterproof To a depth of 1m fully submersed, including a 45°C
thermal shock.
Will withstand petrol, diesel and other fuel oils.
Drop Resistance Will withstand a drop from 1m on to a hard surface on
any face.
