Technical information 9-9
TIGHTEN TORQUE OF BOLT AND NUT IN KEY POSITION OF MAINTENANCE AND
REPAIR
(UNIT: N*m)
1. Engine crankcase drain plug: 29-39
2. Engine adjustment lock nut: 16-21
3. Fueling plug and drain plug of transmission \
power divider: 25-34
4. Transaxle drain plug R: 59-98
5. Bolt and nut of propeller shaft: 39-44
6. Wheel nut: 118-147
7. Steering wheel lock nut: 29-39
8. Steering drive shaft universal joint tighten bolt:
24-29
9. Coupling bolt between steering gear case and
supporter: 84-96
10. Steering rocker arm shaft lock nut
No power steering: 235-265
Power steering: 137-177
11. Steering link ball nut: 54-98
12. Steering tie rod lock nut: 2WD: 14-20
13. Front suspension top swing arm adjustment
bolt: 98-118
14. Front shock absorber bottom tighten bolt:
118-147
15. Rear leaf spring pin and hanger pin lock nut:
78-98
16. Rear leaf spring U-shape bolt and nut: 88-98
17. Seat belt abutment anchor bolt: 43-55
DRIVER’S TOOLS
No.
Name
Amount
note
1
Kit bag
1
2
Wheel sleeve
1
No.
Name
Amount
note
3
Jack
assembly
1
4
Jack bar
1
