Saito FG-40 - Page 2

64
129
28
M8x1.25
69
86
70
54
27
4-Ø4.3
35
35
71
155.5
84.5
44
16
30
Outsidedimensions
●Asexhaustsmokeisharmful,becarefulnottobreatheinorotherwiseexposeyourselftoitsharmfuleffects.
●Payattentionnottotouchtherotatingpropellerwhenstartingengine,andmovetorearsideoftheaircraftoncetheengineisstarted.
●Allresponsibilitiesfortheuseoftheengine,andotherobligationsandresponsibilitiesbasedonlaws,regulations,etc.arebornebythe
purchaserandtheuser,andSAITOSEISAKUSHOCO.,LTD.isexemptfromanyresponsibilities.
Warranty:
●Ifthereisanydeficiencyfromthefactoryconcerningmanufacture,pleaseconsultwiththeshopordistributoryouboughtfrom.Our
companywillberesponsibleforrepair.However,anyfailureortroublecausedbyunnecessarydisassembly,modification,orotherusesthan
thoseprovidedintheinstructionmanualisnotsubjecttowarranty.
●Ignitionsystemissubjecttothewarrantyonlyforinitialfailure.Oncethesystemhasbeenactivatedsuccessfully,itwillnolongerbesubject
towarranty.
SAITOSEISAKUSHO,CO.,LTD.www.saito-mfg.com
22-7,3-chome,Tokagi,Ichikawa-shi,Chibaprefecture272-0024,JapanPhone:047-378-4156FAX:047-378-4155
Allspecificationsandmodelsaresubjecttochangewithoutnotice.
FG-40PartsList
No.
01
06
07
08
09
10
14
15
17
19
20
22
23
27
28
31
32
33
35
36
37
38
39
40
41
42
Qty
1
1
1
2
1
1
1set
1
1
1
1
1
1
1ea.
1ea.
1set
1set
1
1
1
1set
2
2
2ea.
2
2ea.
Item
Cylinder
Piston
Pistonpin
Pistonpinretainer
Pistonring
Connectingrod
Cylinderscrewset
14-1,-2,-3,-4
Crankcase
Rearcover
Breathernipple
Frontballbearing
Rearballbearing
Crankshaft
Tapercollet&driveflange
27-1,-2
Propwasher&Nut
28-1,-2
Crankcasescrewset
31-1,-2,-3
Enginegasketset
32-1,-2,-3,-4.-5.-6.-8
Camgearhousing
Camgear
Camgearshaft
Steelwasherset
Tappet
Pushrod
Pushrodcover&Rubberseal
40-1,-2,-3
Rockerarm
Rockerarmscrew&nut
41-1,-2
No.
43
44
45
46
47
48
49
69
74
75
80
82-1
83-1
90
91
93
95
110
120
149
152
153
Qty
2
1
1
1set
2ea.
2
2
1
1
1set
2
1set
1set
1set
1set
1
1set
1
1
1
1
1set
Item
Rockerarmpin
Rockerarmbracket(left)
Rockerarmbracket(right)
Valveset(In&Ex)
46-1,-2
Valvespring&Keeper&Retainer
47-1,-2,48
Valveretainer
Rockerarmcover
Intakemanifold(Intakepipe)
Muffler
Mufflermanifoldset
75-1,80
Mufflernut
Carburetorcomplete
Carburetorbodyassembly
82-1-1,-1-2,-1-3,-1-4,-1-5,-1-13
Carburetorscrew&springset
82-1-9,-1-10,-1-11,-1-12
Carburetorgasketset
82-1-6,-1-7,-1-8
Intakevelocitystack(airfunnel)
Enginemountset
95-1,-2,-3,-4,-5
Antilooseningnut
Sparkplug(CM-6)
Oilslinger
Screwpin(Fordriveflangesetting)
Electronicignitionsystem
153-1,-2,-3,-4,-5
153
153ｰ1
153ｰ4
153ｰ3
153ｰ2
