Light Commercial R410A on-off
S13-01.01.13en
z
current(RLA)
copper tube
side
heating:-5~24
Notes: 1. Nominal cooling capacities are based on the following conditions:
Indoor temp: 27°CDB, 19°CWB; Outdoor temp: 35°CDB;
Nominal heating capacities are based on the following conditions:
Indoor temp: 20°CDB; Outdoor temp: 7°CDB, 6°CWB;
Actual noise level may differ, depending on the room structure, etc, since these noise values are from an anechoic
room.
2.
3.
Outdoor Units
84
Model SOB-100YA SOB-140YA SOB-200YA
Power supply
V-ph-H
380~415-3-50 380~415-3-50 380~415-3-50
Max. input consumption W 4950 6300 7500
Max. input current A 10 10.5 12.6
Compresso
r
Model C-SBN303H8D C-SBN373H8D C-SBN453H8D
Type SCROLL Scroll Scroll
Brand SANYO Sanyo Sanyo
Capacity Btu/h 33438 48109 55956.8
Input W 3650 4750 5750
Rated
A 6.58 8.22 9.77
Locked rotor
Amp(LRA)
A 48 66 67
Thermal protector Internal Internal Internal
Capacitor μF --
-- ---
Refrigerant oil
ml
FV68S/1700
FV68S,1700
FV68S, 1700
Outdoor fan
motor
Model YDK190-6D(B) YDK65-6/YDK65-6F YDK65-6+YDK65-6F
Qty 1 2 2
Input W 290 148+156 148+140
Capacitor μF 10μF/450V (3.5UF/450V)×2
(3.5μF/450V)×2
Speed r/min 830 800 800
Outdoor
coil
Number of rows 2 2 2
Tube pitch(a)× row
pitch(b)
mm 21x13.37 21×13.37 22×19.05
Fin spacing mm 1.4 1.4 1.6
Fin type Hydrophilic aluminum Hydrophilic aluminum Hydrophilic aluminum
Tube outside dia.
and type
mm
φ7, Inner grooved
copper tube
φ7 Inner grooved
copper tube
φ7.94 Inner grooved
Coil length × height
× width
mm
890x903x26.74
840×1113×26.74
837×1100×38.1
Number of circuits 7 4 8
Outdoor air flow
m
3
/h
5000 6800 6850
Outdoor noise level (sound
pressure)
dB(A) 57 59 59
Outdoor
unit
Dimension(W×H×D)
mm 990×966×354 900×1167×340 900×1167×340
Packing
(W×H×D)
mm 1120×1100×435 1032×1307×443 1032×1307×443
Net/Gross weight kg 94/96 102/106 106/111
Refrigerant
Type R410a R410a R410A
Charged volume g 2900 3250 3200
Throttle type capillary capillary capillary
Design pressure MPa 4.2/1.5 4.2/1.5 4.2/1.5
Refrigerant
piping
Liquid side/ Gas
mm φ12.7/φ19 φ12.7/φ19 φ12.7/φ19
Max. pipe length m 30 50 50
Max. difference in
level
m 20 25 25
Ambient temp.
℃
cooling: 21~43;
heating:-5~24
cooling: 21~43;
heating:-5~24
cooling: 21~43;
