功能指示灯说明：
Function indicate lamp instruction:
◊ RUN：灯灭时表示变频器处于停机状态，灯亮时表示变频器处于运转状态。RUN: lamp
extincted means the frequency converter be at stop machine status, lamp lighting means the frequency
converter be at running status.
LOCAL/REMOTE 熄灭 extincted
面板启停控制 Panel start-stop control
LOCAL/REMOTE 常亮 normally lighting
端子启停控制 Terminal start-stop control
LOCAL/REMOTE 闪烁 flashing
通讯启停控制 Communication start-stop control
◊ LOCAL/REMOT：键盘操作、端子操作与远程操作（通信控制）指示灯：
LOCAL/REMOT: keyboard operation, terminal operation and remote operation
(communication control) indicate lamp:
◊ FWD/REV：正反转指示灯，灯亮表示处于正转状态。FWD/REV:forward and reverse
running indicate lamp, lamp lighting means it be at forward status.
◊ TUNE/TC：调谐/转矩控制/故障指示灯，灯亮表示处于转矩控制模式，灯慢闪表示处 于
调谐状态，灯快烁表示处于故障状态。TUNE/TC: tune/torque control/failure indicate
lamp, lamp lighting means it be at torque control mode, lamp slow flashing means it
be at tune status, lamp quick flashing means it be at failure status.
2）单位指示灯:Unit indicate lamp:
Hz
频率单位
Frequency unit
A
电流单位
Current unit
V
电压单位 Voltage unit
RPM(Hz+A)
转速单位 Speed unit
%(A+V)
百分比 Percentage
3）数码显示区：Digit display area:
5 位 LED 显示，可显示设定频率、输出频率，各种监视数据以及报警代码等。5 bit LED display,
able to display the setting frequency and output frequency, various monitor data and alarm code, etc.
