SAL VB 4100 - TECHNICAL SPECIFICATIONS AND WIRING; SYSTEM PARAMETERS AND SPECIFICATIONS; WIRING DIAGRAMS FOR CONNECTORS

28
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
B
A
POWER CONNECTION FOR THE BLACK ISO PLUG
A/1. No connection
A/2. No connection
A/3. No connection
A/4. Battery direct connection for memory, +12 V (yellow)
A/5. Remote only for motor car antenne or amplifier REM, +12 V (blue)
A/6. No connection
A/7. Ignition switch, +12 V (red)
A/8. Battery / Chassis GND (black)
CONNECTION OF 4 SPEAKERS FOR THE BROWN ISO PLUG
B/1. Speaker Out Right Rear +
B/2. Speaker Out Right Rear -
B/3. Speaker Out Right Front +
B/4. Speaker Out Right Front -
B/5. Speaker Out Left Front +
B/6. Speaker Out Left Front -
B/7. Speaker Out Left Rear +
B/8. Speaker Out Left Rear -
Do not connect any speaker cable to the GND of the car or the battery (with the black cable or chassis)!
VB 4100
FM TUNER
FM freq. range 87,5-108,0 MHz
FM preset 18 x FM
Usable sensitivity 1,6 V
Channel separation >42 dB
Signal/noise level >54 dB
USB/SD
USB system USB 2.0
Max. current 500 mA
File system FAT 16/32, max. 32 GB
MP3 decoder MPEG-1/2 AUDIO Layer-3
Number of channels 2-CH, stereo
Channel separation >72 dB
Signal/noise level >83 dB
GENERAL PARAMETERS
Car Voltage system 12 Volt Negative GND chassis
Operation Voltage 14,4 V DC (9 -15 V)
Type of display Touch panel LCD
Channels of amplier 4 CH
Power output 4 x 45 W max.
Speaker impedance 4 – 8 Ohm
Frequency range 20 - 20.000 Hz
Pre-amp output 2 V max. (2+2 x RCA)
Fuse F10A
T operation 0˚C …+40˚C
Weight 490 g
Chassis dimensions 178 x 50 x 130 mm
