Minimum inlet pressure (above atmospheric pressure) at the pump suction port
in order to avoid cavitation noises (at fluids temperature T
Med
):
The values apply up to 300 m above sea level; addition for higher locations:
0.01 bar/100 m increase in height.
5.3 Scope of delivery
• Pump, complete
• Two seals for threaded connection
• Two seals and bolts for flange connection
• Eight M12 washers
(for M12 flange bolts for DN 32-DN 65 combination flanged version)
• Eight M16 washers
(for M16 flange bolts for DN 32-DN 65 combination flanged version)
• Installation and operating instructions
5.4 Accessories
Accessories must be ordered separately:
• Change-over switch for 3~230 V
• Kit-press 6 or Kit-press 16
SCX/SXM/DCX/DXM
T
Med
Rp ¾ Rp 1 Rp 1¼ DN 32/40 DN 50 DN 65 DN 80 DN 100
+50 °C 0.05 bar 0.3 bar
+95 °C 0.5 bar 1.0 bar
+110 °C 1.1 bar 1.6 bar
+130 °C 2.4 bar(*) 2.9 bar(*)
(*) not applicable to SXM 25-90, SCX/DCX 80-110 et 80-150
NSB-S, SXS
T
Med
Rp ¾ Rp 1 Rp 1¼ DN 40 DN 50 DN 65 DN 80
+50 °C 0.5 bar 0.8 bar
+80 °C 0.8 bar 1.0 bar
+110 °C 2.0 bar 3.0 bar
