SALUPO DRY CONTROL PLUS - Wiring Diagram SA607.xx

ENGLISH
1 2
G.MIN
COM
MIN
COM
MAX
G.MAX1
3 4
R
MOT1
S
R S T
SUPPLY
EXPANSION BOARD
Max 10 mm²
(M4)
0,8Nm
10 mm
Max 6 mm²
(M4)
2,5Nm
10 mm
Max 2.5 mm²
(M3)
0,5Nm
8,3 mm
L1 L2 L3
U V W
M
3
MOTOR
POWER SUPPLY
400 Vac 50/60 Hz
4. WIRING DIAGRAMS
4.2 Wiring diagram SA607.xx
1 2
G.MIN
COM
MIN
COM
MAX
G.MAX1
3 4
COM
MIN
MAX
EXTERNAL COMMAND 1 INPUT
EXTERNAL COMMAND 2 INPUTS
FILLING FUNCTION
FLOAT SWITCH OR PRESSURE SWITCH
21
