Salus EVT7EU - Technical Specifications

9
Technical Specications
Technical specifications
SINGLE PHASE (EVT7EU / EVT7UK) THREE PHASE (EVT11EU)
Input voltage 230V AC 50Hz 400V AC 50Hz
Charging current & power 32A / 7kW 16A / 11kW
Charging mode Mode 3
Charging connector 5 meter type 2 charging cable
Cable section Up to 10mm
Cable entry Bottom and rear side
Electrical protection
6mA DC residual current detection
Anti-welding protection
Over current protection
Over/under voltage protection
Over temperature protection
Surge protection
PEN fault protection (EVT7UK only), without the need for
additional earth rod installation.
LED display LED backlight for logo and multi-colour LED for charging status
NFC reader Mifare (13.56MHz), ISO14443-A
Connectivity IEEE 802.11bgn Wi-Fi (2.4GHz)
Communication Mobile App operation
Firmware update Over the air firmware update capability
Security Wi-Fi : WEP, WPA-TKIP, WPA2-CCMP, PMF and WPA3
Ingress protection rating IP65
Impact protection rating IK08
Material (Enclosure) PC UV stabilized (UL94 V-0 fire rated)
Storage temperature -30°C to 80°C
Operating temperature 7kW model : -25°C to 50°C 11kW model : -25°C to 45°C
Operating humidity Up to 95% RH (non-condensed)
Working altitude Up to 2,000m
Dimensions (H x W x D) 231mm x 231mm x 70mm
Net weight 4.7kg
Accessory
Y-shape mount
NFC card x 3 pcs
Cable and connector holder
