SUN_IS_ electrical_installation_v5.1_06092021
20
4. Fix the siren to the U-profile with screws phi 4 mm, length 15 mm.
5. Fit double WAGO connectors on each wire.
6. Fit 0.75 mm
2
cable lugs on wire "3". Then connect the wires from the siren to the
harness with WAGO connectors according to the colors in the picture.
7. Screw the siren to the structure with a screw phi 4 mm, length 15 mm, and place the wires.
