8. Twist the wooden U-profile and lay the wires.
X. INSTALLATION OF THE HUUM TEMPERATURE SENSOR
1. Solder the ends of the wires to make it easier to attach them to the sensor. Using a small
screwdriver, screw them onto the sensor mounts.
2. Drill a hole using a drill phi 2.5, then screw in the bottom mounting screw. Slide the sensor onto
the screw. Once it is level, drill a second hole.
3. Pre-screw the bolt into the hole and insert the sensor, then tighten the bolt through the "H" hole.
