Installation – User Interface
ICON FUNCTION
Floor sensor probe indicator:
Show only when Air + Floor sensor is connected.
Setting indicator:
Indicates the unit is in setting mode when program setting.
Indicate’s the manual mode.
Keylock indicator:
Shows that keys are inactive.
14
15
16
14 VS30W and VS30B Installer Manual
