Installation – Thermostat Mounting
1
3
2
60mm
Wall Mounting
For wall mounting, mark and
mount the rear case to the wall.
The VS30 is suitable for wall boxes
with a centre hole distance of : 60mm
Gently remove front housing.
06 VS30W and VS30B Installer Manual
Gently remove front housing.
Only for ush
mounting boxes
with horizontal
xing holes.
