7
Direction of Rotation: Clockwise and Anti-Clockwise pump viewed
from driven end.
ERECTING THE PUMP: The assembly of the pump with the driver on a
common base plate is done in our works, the whole set will be carefully
mounted and aligned. It is necessary to check once more the alignment of
the coupling before putting the pump into operation. The eye bolts which
may be fitted to the driver must never be used to lift the complete set as
they are meant to carry the weight of the driver only.
2.
3.
4.
5.
