102 | SAMLEX AMERICA INC.
SECTION 5 | SD Card
5.4 SAVING / UPLOADING PROGRAMMED PARAMETERS
5.4.1 Saving Programmed Parameters
All the programmed parameters can be saved on an SD Card (FAT 16 / FAT 32 Format, up to 16 GB capacity). The
parameters will be saved in File named “xxxx_yyy.cfg”, where the rst group of 4 digits xxxx is the Model No. e.g. 2212
or 2224 or 3012 or 4024 and the second group of 3 digits YYY is the Revision No. for that model.
• For saving, rst insert the SD Card in the SD Card Slot.
• Then, go to “Parameter Save” Screen (See Section 4.8.2.11). Steps are given below:
5.4.1.1 Programming Steps for Parameter "PARAMETER SAVE"
5.4.2 Uploading Saved Parameters
If there is a “xxxx_yyy.cfg” le in the SD card with stored programmed parameters, then on inserting the card, the
Remote Control will ask to upload the Cong File. Press Enter Button to conrm or Back Button to cancel.
U p l o a d c o n f ?
Y e s = E n t e r k e y
N o = B a c k k e y
• Asks to conrm or cancel uploading of saved parameters.
• Choose Yes by pressing Enter Key.
U p l o a d c o n f
1 %
Conguration uploading.
Password 8052
See Section 4.3.1
S e l e c t G r o u p
* C H A R G E C U R V E
ð
S e l e c t P a r a m e t e r
* O T H E R F U N C T I O N
ð
S e l e c t P a r a m e t e r
O T H E R F U N C T I O N
* P O W E R S A V I N G
0 = D i s a b l e
S e l e c t P a r a m e t e r
O T H E R F U N C T I O N
* P A R A M E T E R S A V E
0 = N o
Down Key x 4 times
Enter Key Down Key x 10 times
ð
P a s s w o r d k e y i n
0 0 0 0
ð
S e l e c t P a r a m e t e r
O T H E R F U N C T I O N
* P A R A M E T E R S A V E
0 = N o
Enter Key
S e l e c t P a r a m e t e r
O T H E R F U N C T I O N
P A R A M E T E R S A V E
1 = Y e s
ð
S a v e d f i l e e n d .
ð
S e l e c t P a r a m e t e r
O T H E R F U N C T I O N
* P A R A M E T E R S A V E
0 = N o
Down Key
Press Enter Key, hold for
3 to 4 sec and release
