SAMLEX AMERICA INC. | 13
Table 3.1 Operating Modes and Associated Menu Maps/ LCD Display Screens
Operating
Mode
Display Description
Operating Mode
Screen Menu Map
Models
EVO-1212F /
1212F HW / 1224F /
1224F-HW
Models
EVO-2212 / 3012 /
2224 / 4024
Standby Standby Mode: No output, No AC bypass, No Charging Fig 3.1(a),
Section 3.6.2.1
Fig 3.1 (b),
Section 3.6.2.2
Inverting Unit is operating as an inverter Fig 3.2(a),
Section 3.6.3.1
Fig 3.2(b),
Section 3.6.3.2
Charging Unit is operating as a battery charger and passing through the
AC input to the loads
Fig 3.3(a),
Section 3.6.4.1
Fig 3.3(b),
Section 3.6.4.2
PowerSave Unit is in Power Saving Mode Fig 3.4(a),
Section 3.6.5.1
Fig 3.4(a),
Section 3.6.5.2
Online Unit is in On Line Mode Fig 3.5, Section 3.6.6
Chrg Only Under "ONLINE MODE" only (Option 2=Charger Only). Pro-
vides charging and pass through when the AC input is avail-
able. No inverting when the AC input is not available.
Fig 3.6(a),
Section 3.6.7.1
Fig 3.6(b),
Section 3.6.7.2
Charger Stop
by BMS
Applicable when BATTERY TYPE Option 1=Lithium is selected.
This mode is activated when the Lithium Battery Management
System (BMS) sends command to EVO
™
(contact closure
signal) to stop charging to prevent battery over voltage or over
temperature.
Fig 3.7, Section 3.6.8
Inverter stop
by BMS
Applicable when BATTERY TYPE Option 1=Lithium is selected.
This mode is activated when the Lithium Battery Management
System (BMS) sends command to EVO
™
(contact closure signal)
to stop inverting to prevent deep discharge of the battery.
Fig 3.8, Section 3.6.9
3.6.2 Menu Map for Standby Mode Screens
Menu Maps for the Operating Mode Screens for the Standby Mode are shown as follows:
• Section 3.6.2.1: Fig 3.1(a) for Models EVO-1212F / 1212F-HW / 1224F / 1224F-HW
(Model No. shown in the screens is EVO-1212F)
• Section 3.6.2.2: Fig 3.1(b) for Models EVO-2212 / 3012 / 2224 / 4024
(Model No. shown in the screens is EVO-3012)
SECTION 3 | Operation
