Samlexpower EVO-RC-PLUS - Page 50

50 | SAMLEX AMERICA INC.
SECTION 4 | Parameter Setup
TABLE 4.4 CHARGING PROFILE FOR 4-STAGE ADAPTIVE CHARGING FOR EQUALIZATION
Srl
No.
Options under
Programming
Parameter
“EQUALIZE–4 STAGES”
Charging Stages Battery Type
1
EQUALIZE – 4 STAGES
0 = No (Default Setting)
1 = Yes
1. Stage 1 – Bulk Stage (See Section 5.8.2 of the EVO-
1212F/1212F-HW/1224/1224F-HW Owner’s Manual
for details):
• Charge at constant current (CC) = the programmed value of
parameter “BULK CURRENT”
(Default value is 20A. For details of
programming range & procedure, refer to Section 4.4.2.1)
• Transition to Absorption Stage when voltage rises to the
set value for programming parameter “ABSORP VOLTAGE”
(Default value is 14.4V for EVO-1212F/1212F-HW and 28.8V for EVO-
1224F/1224F-HW. For details of programming range & procedure, refer to
Section 4.4.2.2)
2. Stage 2 - Absorption Stage (See Section 5.8.2 of the EVO-
1212F/1212F-HW/1224/1224F-HW Owner’s Manual for
details):
• Charge at constant voltage (CV) = the programmed value
for parameter “ABSORP VOLTAGE”. (Default value is 14.4V for
EVO-1212F/1212F-HW and 28.8V for EVO-1224F/1224F-HW. For details of
programming range & procedure, refer to Section 4.4.2.2)
• Adaptive Time Algorithm: Time in Absorption Stage is
computed automatically based on time in Bulk Stage (See
Section 5.8.2 of the EVO-1212F/1212F-HW/1224/1224F-HW
Owner’s Manual for details)
• Transition to Equalization Stage thereafter.
3. Stage 3 - Equalization Stage (Section 5.8.2 of the
EVO-1212F/1212F-HW/1224/1224F-HW Owner’s
Manual for details):
• Charge at constant voltage (CV) = the programmed value
of parameter “EQUALIZE VOLTAGE”.
(Default value is 14.4V for
EVO-1212F/1212F-HW and 28.8V for EVO-1224F/1224F-HW. For details of
programming range & procedure, refer to Section 4.4.2.3.
• Adaptive Time Algorithm: Time in Equalization Stage is
computed automatically based on time in Bulk Stage. (See
Section 5.8.2 of the EVO-1212F/1212F-HW/1224/1224F-HW
Owner’s Manual for details)
• Transition to Float Stage thereafter.
4. Stage 4 -
This stage will be the same as the last Stage of Charging Prole
from where Equalization was started. (For details, refer to
Table 5.2.1 under Section 5.8.2.4 of the EVO-1212F/1212F-
HW/1224/1224F-HW Owner's Manual)
− Lead Acid: Flooded only
!
CAUTIONS!
1. Equalize Flooded Lead Acid Batteries only.
Sealed AGM / Gel Cell types of batteries are
NOT equalized
2. Refer to Section 5.8.2 and Fig 5.2 of
the Manual for EVO-1212F/1212F-
HW/1224/1224F-HW.
3. The Adaptive Charging Algorithm measures
the Bulk Stage Time (T0) to automatically
compute Absorption Stage Time (T1') and
Equalization Stage Time (T2). This algorithm
is fully effective only when there are no
other external DC loads being supplied by
the battery that may divert full or part of
the BULK CURRENT resulting in undesired
increase in Bulk Stage Time “(T0)” and
consequently, undesired increase of
Absorption Stage Time (T1') and Equalization
Stage Time (T2). Hence, disconnect all other
external DC loads on the battery during the
equalization cycle.
!
ATTENTIONS!
1. Égaliser les batteries au plomb inondées
seulement. Les batteries scellées de type
AGM / cellules au gel ne sont pas égalisées.
2. Se reporter à la section 5.8.2 et
gure 5.2 du manuel pour EVO-
2212/3012/2224/4024.
3. L'algorithme de charge adaptative l'essentiel
des mesures de phase (T0) pour calculer
automatiquement l'étape d'Absorption
Temps (T1') et de la péréquation, le temps
(T2). Cet algorithme n'est pleinement
efcace que lorsqu'il n'y a pas d'autres
charges c.c. externe alimenté par la
batterie qui peut détourner tout ou
partie de l'ACTUEL EN VRAC résultant
en une augmentation indésirable en vrac
temps Étape "(T0)" et par conséquent,
augmentation indésirable de l'étape
d'Absorption Temps (T1') et de la
péréquation le temps (T2). Par conséquent,
déconnectez toutes les autres charges CC
externes sur la batterie pendant le cycle
d'égalisation.
