SAMLEX AMERICA INC. | 51
SECTION 4 | Parameter Setup
4.4.2.12.1 Programming Steps for Parameter "EQUALIZE-4STAGES"
ð ð
E V O - 1 2 1 2 F I n v e r t i n g
A C o u t p u t : 1 2 0 . 0 V
< 0 . 1 0 A
6 0 . 0 0 H z
Enter Key Enter Key
Any Operating Mode Screen from
Fig 3.1 to 3.5
[Above screen is Screen 1 of Fig 3.2(a)]
Password 8052
See Section 4.3.1
See Table 4.3, Parameter Setup
Screen No. 12 for
programmable options
S e l e c t G r o u p
* C H A R G E C U R V E
ð
S e l e c t P a r a m e t e r
C H A R G E C U R V E
* B U L K C U R R E N T
2 0 A
ð
S e l e c t P a r a m e t e r
C H A R G E C U R V E
* E Q U A L I Z E - 4 S T A G E S
0 = N o
S e l e c t P a r a m e t e r
C H A R G E C U R V E
* E Q U A L I Z E - 4 S T A G E S
0 = N o
Enter Key
Down Key x 11 times
P a s s w o r d k e y i n
0 0 0 0
ð
Enter Key
4.4.2.13 MODE (Table 4.3, Screen No. 13)
Under Parameter "MODE" Menu, the following 3 options can be programmed:
• Option "0=Normal" (Also called "Ofine Mode" with Grid/ Generator priority. This is the Default option)
• Option "1=Online" (Also called "Online Mode" with Inverter priority)
• Option "2=Charger Only" (explained further at Section 4.4.2.13.1)
For more information on the applications of parameter "MODE" and its 3 options, please refer to the following sections:
• Section 4.6.5 of Owners Manual for Models EVO-1212F / 1212F-HW / 1224F / 1224F-HW
• Section 4.8.5 of Owners Manual for Models EVO-2212 / 3012 / 2224 / 4024
4.4.2.13.1 Charger Only Mode (Table 4.3, Screen No. 13)
Under Parameter "MODE" (Section 4.4.2.13), 3 options can be programmed: "0=Normal" (Off-line Mode) or,
"1=Online" or, "2=Charger Only".
When “Charger Only” Mode is selected (Option "2=Charger Only"), EVO™ will charge the batteries and pass through
the AC input power to the loads as long as AC input is available.
• Operating Mode Screens for Charging Mode will be displayed (See Operating Mode Screens in the Charging
Mode Menu Map at Fig 3.3(a) for EVO-1212F / 1212F-HW / 1224F / 1212F-HW and at Fig 3.3(b) for EVO-2212 /
3012 / 2224 / 4024). Extract of Screen No.1 for EVO-1212F is shown below as an example.
E V O - 1 2 1 2 F C h a r g i n g
0 - B u l k S t a g e
B a t t : 1 2 . 0 0 V 1 0 0 . 0 A
E x t e r n a l :
0 . 0 A
When the AC input fails, the Inverter Section will NOT be activated and the AC side loads will lose AC power. The
EVO™ will operate in Standby Mode as long as AC input power is NOT available.
• Operating Mode Screens for Standby Mode will be displayed (See Operating Mode Screens in the Standby Mode
Menu Map at Fig 3.1(a) for EVO-1212F / 1212F-HW / 1224F / 1212F-HW and at Fig 3.1(b) for EVO-2212 / 3012 /
2224 / 4024). Extract of screen for EVO-1212F is shown below as an example.
