SECTION 4 | Parameter Setup
4.4.2.21 CHARGING PROFILE (Table 4.3, Parameter Setup Screen No. 21)
Parameter “CHARGING PROFILE” provides 6 options for Charging Proles that are designed to cover various charging
requirements for Lead Acid, Nickel-Zinc (Ni-Zn) and Lithium Ion Batteries.
i
INFO
7th Charging Prole i.e. 4-Stage Adaptive Charging Prole for Equalization is also available and can be activated
at any time during charging taking place under 1 of the 6 Charging Prole options given at Table 4.5. Procedure
to activate 4-Stage Adaptive Charging Prole for Equalization is described under programming parameter
“EQUALIZE- 4 STAGES” at Section 4.4.2.12
The 6 options under parameter "CHARGING PROFILE" are as follows:
• 0 = 3 Stage Adaptive (Default)
• 1 = 3 Stage Type 1
• 2 = 3 Stage Type 2
• 3 = 2 Stage Type 1
• 4 = 2 Stage Type 2
• 5 = 2 Stage Type 3
NOTE: 3-Stage Adaptive Charging Prole option “0 = 3 Stage Adaptive (Shown as “0=3 Stg Adaptive” in the
programming screen)” is the default charging prole applicable for Lead Acid Batteries
Details of the 6 programmable charging proles under programming parameter “CHARGING PROFILE” are given in
TABLE 4.5.
!
CAUTION!
The Battery Management System (BMS) that comes with the type of Lithium Ion Battery being used
will need to have control over charging and discharging of the Lithium Ion battery. For this, any
of Pins 1/2/3/4 and 5/6/7/8 of the Temperature Sensor Jack (6, 19 in Fig 2.1 in EVO-1212F/1212F-
HW/1224F/1224F-HW Owner’s Manual ) may be used to feed potential free contact closing signal
from the BMS to “Stop Charging” or “Stop Inverting” [Refer to Section 4.4.2.22.2 for details]
!
ATTENTIONS!
Le système de gestion de la batterie (BMS) fourni avec le type de batterie au lithium-ion utilisé
doit pouvoir contrôler la charge et le déchargement de la batterie. Pour cela, l’un des broches
1/2/3/4 et 5/6/7/8 de la prise du capteur de température (6, 19 Fig 2.1 dans le manuel d’utilisation
EVO-1212F/1212F-HW/1224F/1224F-HW fourni) ) peut être utilisé pour alimenter le signal de
fermeture de contact libre de potentiel du système de management jusqu'à "Stop Charging" ou
"Stop Inverting" [Voir la section 4.4.2.22.2 pour plus de détails]
