SECTION 4 | Parameter Setup
3
2=3Stage Type2 1. Stage 1 – Bulk Stage (For details, see Section 5.7.1.1 of the Owner's Manual for EVO-
1212F/1212F-HW/1224F/1224F-HW):
• Charge at constant current = the programmed value of parameter “BULK
CURRENT” (For details of programming range & procedure, refer to Section 4.4.2.1
• Transition to Absorption Stage when voltage rises to the set value for programming
parameter “ABSORP VOLTAGE”
(For details of programming range & procedure, refer to Section
4.4.2.2
2. Stage 2 - Absorption Stage (For details, see Section 5.7.2 of the Owner's Manual for
EVO-1212F/1212F-HW/1224F/1224F-HW):
• Charge at constant voltage = the programmed value for parameter “ABSORP
VOLTAGE”. (For details of programming range & procedure, refer to Section 4.4.2.2)
• Remain in Absorption Stage till the current reduces to value = the programmed
value of parameter “ABSORP EXIT AMPS” (For details of programming range & procedure, refer
to Section 4.4.2.20)
• Transition to Float Stage thereafter.
3. Stage 3 - Float Stage (For details, see Section 5.7.3 of the Owner's Manual for EVO-
1212F/1212F-HW/1224F/1224F-HW):
• Charge at constant voltage = the programmed value of parameter “FLOAT
VOLTAGE”. (For details of programming range & procedure, refer to Section 4.4.2.4 )
• Reset to Bulk Stage under the following conditions:
i. If the AC input fails or is switched off and is restored subsequently.
ii. If battery voltage falls to the programmed value of parameter "RESET TO
BULK". (For details of programming range & procedure, refer to Section 4.4.2.15).
iii. If the charger remains in the Float Stage for 10 days
− Lead Acid: Flooded
and Sealed – AGM/
Gel Cell
− Lithium (For details,
see Section 5.11 of
Owner's Manual for
EVO-1212F/1212F-
HW/1224F/1224F-HW)
4
3=2Stage Type1 1. Stage 1 – Bulk Stage (For details, see Section 5.7.1.1 of the Owner's Manual for EVO-
1212F/1212F-HW/1224F/1224F-HW):
• Charge at constant current = the programmed value of parameter “BULK
CURRENT” (For details of programming range & procedure, refer to Section 4.4.2.1
• Transition to Absorption Stage when voltage rises to the set value for programming
parameter “ABSORP VOLTAGE” (For details of programming range & procedure, refer to Section
4.4.2.2
2. Stage 2 - Absorption Stage (For details, see Section 5.7.2 of the Owner's Manual for
EVO-1212F/1212F-HW/1224F/1224F-HW):
• Charge at constant voltage = the programmed value for parameter “ABSORP
VOLTAGE”. (For details of programming range & procedure, refer to Section 4.4.2.2)
• Remain in Absorption Stage till the time in Absorption Stage is = the programmed
value of parameter “ABSORP TIME” (For details of programming range & procedure, refer to
Section 4.4.2.19)
• Switch off charging after expiry of programmed value of parameter “ABSORP TIME”
(For details of programming range & procedure, refer to Section 4.4.2.19)
• Reset to Bulk Stage under the following conditions:
i. If the AC input from the Grid/Generator is disconnected and is reconnected.
ii. If battery voltage falls to the programmed value of parameter "RESET TO
BULK" . (For details of programming range & procedure, refer to Section 4.4.2.15).
− Lithium (For details,
see Section 5.11 of
Owner's Manual for
EVO-1212F/1212F-
HW/1224F/1224F-HW)
− Nickel Zinc (For details,
see Section 5.10 of
Owner's Manual for
EVO-1212F/1212F-
HW/1224F/1224F-HW)
To Next Page
