60 | SAMLEX AMERICA INC.
SECTION 4 | Parameter Setup
5
4=2Stage Type2 1. Stage 1 – Bulk Stage (For details, see Section 5.7.1.1 of the Owner's Manual for EVO-
1212F/1212F-HW/1224F/1224F-HW):
• Charge at constant current = the programmed value of parameter “BULK
CURRENT” (For details of programming range & procedure, refer to Section 4.4.2.1
• Transition to Absorption Stage when voltage rises to the set value for programming
parameter “ABSORP VOLTAGE”
(For details of programming range & procedure, refer to Section
4.4.2.2
2. Stage 2 - Absorption Stage (For details, see Section 5.7.2 of the Owner's Manual for
EVO-1212F/1212F-HW/1224F/1224F-HW):
• Charge at constant voltage = the programmed value for parameter “ABSORP
VOLTAGE”. (For details of programming range & procedure, refer to Section 4.4.2.2)
• Remain in Absorption Stage
• Reset to Bulk Stage under the following conditions:
i. If the AC input fails or is switched off and is restored subsequently
ii. If battery voltage falls to the programmed value of parameter "RESET TO
BULK" . (For details of programming range & procedure, refer to Section 4.4.2.15).
− Lithium (For details,
see Section 5.11 of
Owner's Manual for
EVO-1212F/1212F-
HW/1224F/1224F-HW)
6
5=2Stage Type3 1. Stage 1 – Bulk Stage (For details, see Section 5.7.1.1 of the Owner's Manual for EVO-
1212F/1212F-HW/1224F/1224F-HW):
• Charge at constant current = the programmed value of parameter “BULK
CURRENT” (For details of programming range & procedure, refer to Section 4.4.2.1
• Transition to Absorption Stage when voltage rises to the set value for programming
parameter “ABSORP VOLTAGE” (For details of programming range & procedure, refer to Section
4.4.2.2
2. Stage 2 - Absorption Stage (For details, see Section 5.7.2 of the Owner's Manual for
EVO-1212F/1212F-HW/1224F/1224F-HW):
• Charge at constant voltage = the programmed value for parameter “ABSORP
VOLTAGE”. (For details of programming range & procedure, refer to Section 4.4.2.2)
• Remain in Absorption Stage till the current reduces to value = the programmed
value of parameter “ABSORP EXIT AMPS” (For details of programming range & procedure, refer
to Section 4.4.2.20)
• Switch off charging after the current reduces to value = the programmed value of
parameter “ABSORP EXIT AMPS” (For details of programming range & procedure, refer to Section
4.4.2.20)
• Reset to Bulk Stage under the following conditions:
i. If the AC input fails or is switched off and is restored subsequently
ii. If battery voltage falls to the programmed value of parameter "RESET TO
BULK" . (For details of programming range & procedure, refer to Section 4.4.2.15).
− Lithium (For details,
see Section 5.11 of
Owner's Manual for
EVO-1212F/1212F-
HW/1224F/1224F-HW)
− Nickel Zinc (For details,
see Section 5.10 of
Owner's Manual for
EVO-1212F/1212F-
HW/1224F/1224F-HW)
4.4.2.21.1 Programming Steps for Parameter “CHARGING PROFILE”
ð ð
E V O - 1 2 1 2 F I n v e r t i n g
A C o u t p u t : 1 2 0 . 0 V
< 0 . 1 0 A
6 0 . 0 0 H z
Enter Key Enter Key
Any Operating Mode Screen from
Fig 3.1 to 3.5
[Above screen is Screen 1 of Fig 3.2(a)]
Password 8052
See Section 4.3.1
See Table 4.3, Parameter Setup
Screen No. 21 for
programmable options
S e l e c t G r o u p
* C H A R G E C U R V E
ð
S e l e c t P a r a m e t e r
C H A R G E C U R V E
* B U L K C U R R E N T
2 0 A
ð
S e l e c t P a r a m e t e r
C H A R G E C U R V E
* C H A R G I N G P R O F I L E
0 = 3 S t a g e A d a p t i v e
S e l e c t P a r a m e t e r
C H A R G E C U R V E
* C H A R G I N G P R O F I L E
0 = 3 S t a g e A d a p t i v e
Enter Key
Down Key x 20 times
P a s s w o r d k e y i n
0 0 0 0
ð
Enter Key
To Next Page
