SAMLEX AMERICA INC. | 65
SECTION 4 | Parameter Setup
4.4.2.23.4 Programming Steps for Parameter "SAFE CHARGING"
ð ð
E V O - 1 2 1 2 F I n v e r t i n g
A C o u t p u t : 1 2 0 . 0 V
< 0 . 1 0 A
6 0 . 0 0 H z
Enter Key Enter Key
Any Operating Mode Screen from
Fig 3.1 to 3.5
[Above screen is Screen 1 of Fig 3.2(a)]
Password 8052
See Section 4.3.1
See Table 4.3, Parameter Setup
Screen No. 23
for programmable options
S e l e c t G r o u p
* C H A R G E C U R V E
ð
S e l e c t P a r a m e t e r
C H A R G E C U R V E
* B U L K C U R R E N T
2 0 A
ð
S e l e c t P a r a m e t e r
C H A R G E C U R V E
* S A F E C H A R G I N G
0 m i n
S e l e c t P a r a m e t e r
C H A R G E C U R V E
* S A F E C H A R G I N G
0 m i n
Enter Key
Down Key x 22 times
P a s s w o r d k e y i n
0 0 0 0
ð
Enter Key
4.4.2.24 EXT. CHARGER (Table 4.1, Parameter Setup Screen No. 24)
When AC input is available within the programmed window of AC input voltage and frequency, the batteries will be
charged based on the following options selected through programming parameter “EXT. CHARGER”:
i) Programming Parameter “EXT. CHARGER” set at Default Option “0 = Affect” (Section 4.4.2.24 of
Remote-Control Manual EVO-RC-PLUS):
This is the default setting. Under this setting, the total charging current will be as follows:
• Total Charging Current = Charging current from internal AC charger PLUS charging current from the
External Solar Charge Controller
o Charging current from the Internal AC Charger = Programmed value of Parameter “BULK
CURRENT” (Section 4.4.2.1 of Remote-Control Manual for EVO-RC-PLUS) MINUS value of charging
current from the External Solar Charge Controller
i) Programming Parameter “EXT CHARGER” set at Option “0 = Not affect” (Section 4.4.2.24 of Remote
Control Manual EVO-RC-PLUS):
• Total Charging Current = Charging current from internal AC charger PLUS charging current from the
External Solar Charge Controller
o Charging current from internal AC Charger = Full programmed value of Parameter “BULK
CURRENT” (Section 4.4.2.1 of Remote Control Manual for EVO-RC-PLUS)
For further details, please refer to Section 5.4 of the Manual for EVO-1212F/EVO-1212F-HW/EVO-1224F/EVO-1224F-HW
4.4.2.24.1 Programming Steps for Parameter "EXT. CHARGER"
ð ð
E V O - 1 2 1 2 F I n v e r t i n g
A C o u t p u t : 1 2 0 . 0 V
< 0 . 1 0 A
6 0 . 0 0 H z
Enter Key Enter Key
Any Operating Mode Screen from
Fig 3.1 to 3.5
[Above screen is Screen 1 of Fig 3.2(a)]
Password 8052
See Section 4.3.1
See Table 4.3, Parameter Setup
Screen No. 24
for programmable options
S e l e c t G r o u p
* C H A R G E C U R V E
ð
S e l e c t P a r a m e t e r
C H A R G E C U R V E
* B U L K C U R R E N T
2 0 A
ð
S e l e c t P a r a m e t e r
C H A R G E C U R V E
* E X T . C H A R G E R
0
= A f f e c t
S e l e c t P a r a m e t e r
C H A R G E C U R V E
* E X T . C H A R G E R
0 = A f f e c t
Enter Key
Down Key x 23 times
P a s s w o r d k e y i n
0 0 0 0
ð
Enter Key
