SECTION 4 | Parameter Setup
4.6.2.7 DETECT TIME 3 (Table 4.7, Parameter Setup Screen No.7)
This is the time limit in cycles up to which low AC input voltage "CUT-OFF VOLT 3"is allowed.
4.6.2.7.1 Programming Steps for Parameter "DETECT TIME 3"
ð ð
E V O - 1 2 1 2 F I n v e r t i n g
A C o u t p u t : 1 2 0 . 0 V
< 0 . 1 0 A
6 0 . 0 0 H z
Enter Key Down Key x 6 times
Any Operating Mode Screen from
Fig 3.1 to 3.5
[Above screen is Screen 1 of Fig 3.2(a)]
Password 8052
See Section 4.3.1
See Table 4.7, Parameter Setup
Screen No. 7
for programmable range
S e l e c t G r o u p
* C H A R G E C U R V E
ð
S e l e c t P a r a m e t e r
* I N P U T L O W L I M I T
ð
S e l e c t P a r a m e t e r
I N P U T L O W L I M I T
* R E S E T V O L T A G E
1 0 5 . 0 V
S e l e c t P a r a m e t e r
I N P U T L O W L I M I T
* D E T E C T T I M E 3
1 c y c l e
Down Key x 2 times
Enter Key
P a s s w o r d k e y i n
0 0 0 0
ð
Enter Key
S e l e c t P a r a m e t e r
I N P U T L O W L I M I T
* D E T E C T T I M E 3
1 c y c l e
ð
Enter Key
4.7 GROUP 4 PARAMETER SET UP: INPUT HIGH LIMIT
4.7.1 Programming Ranges and Default/ Factory Preset Values of Parameters Under Group 4 –
INPUT HIGH LIMIT
Table 4.8 below gives details of programming ranges and default values of parameters under Parameter Group 4 -
INPUT HIGH LIMIT. Refer to Fig 4.3 under Section 4.1.3.2 for Menu Map for navigating through various parameters
under this Group 4.
Table 4.8 Group 4 Parameter Set Up: INPUT HIGH LIMIT (Refer to Menu Map at Fig 4.3, Section 4.1.3.2)
Parameter
Setup Screen
No.
(Column 1)
Parameter
(Column 2)
Setting range
EVO-1212F
EVO-1212F-HW
(Column 3)
EVO-2212
(Column 4)
EVO-3012
(Column 5)
EVO-1224F
EVO-1224F-HW
(Column 6)
EVO-2224
(Column 7)
EVO-4024
(Column 8)
1 RESET VOLTAGE
120.0 - 150.0V
(Default:125.0V)
2 CUT OFF VOLT 1
120.0 - 150.0V
(Default: 135.0V)
3 DETECT TIME 1
0 - 2000 cycles
(Default: 60 cycles)
4 CUT OFF VOLT 2
120.0 - 150.0V
(Default: 140.0V)
5 DETECT TIME 2
0 - 2000 cycles
(Default: 15 cycles)
6 CUT OFF VOLT 3
120.0 - 150.0V
(Default: 145.0V)
7 DETECT TIME 3
0 - 2000 cycles
(Default: 1 cycle)
