COMPONENTS AND ACCESSORIES
1. Output connnector + Bank 1
2. Output Connector + Bank 2
3. Output Connector - Common
4. Charging Indicator LED
5. Dip Switches for mode selection
6. Jack for Remote Panel
7. Push Switch for Mute Mode
8. LED for Mute Mode indication
9. AC input Power On / Off Switch
10. AC fuse holder
11. Cooling fan
12. Jack for Temperature Sensor
13. AC power cord inlet
14*. Cable with plug
15*. Remote Panel
(*14 & 15 are optional accessories)
16. Temperature sensor element
17. plug
4
7
53
11
12
10 13
14
15
16 17
