1. Switch
2. Connection jack for needle probe
3. Ventilation area
4. Knurl grid holder
5. Protective grille
6. Minimum level indicator
7. Float, minimum level guard
8. Water temperature sensor
9. Heater resistances
10. Stirrer motor
Fig. A
Fig. B
UNE-EN ISO 9001
SAMMIC, S.L. Basarte, 1 - 20720 AZKOITIA - www.sammic.com
05-15 - 2901306/0
ER-0437/1/96
SPECIFICATIONS SMARTVIDE 8 PLUS
Working temperature 5ºC to 95ºC / 41ºF to 203ºF
Resolution display 0.01ºC / 0.1ºF
Time resolution 1 min
Cycle duration 1 min 99 h
Display 3.5” colour TFT
Permitted ambient temperature 5ºC to 40ºC / 41ºF to 104ºF
Maximum capacity 56 l / 14 gal
Power supply 120V/60Hz/1 208-240V/50-60Hz/1 230V/50-60Hz/1
Power consumption 11A 9A 9A
Power 1,400W 2,000W 2,000W
Dimensions (Width x Depth x Height) 124mm x 140mm x 360mm / 4.9” x 5.5” x 14.2”
Net weight 4.1kg / 9lb.
