Dimensiones
Solo DF30T
Solo DF50T
DF30 / DF30T
A B C D E F G H I J K L M N P
130 mm 160 mm 162 mm 105 mm 122 mm 8 mm 140 mm 135 mm 70 mm 1/2"
BSP
NPT
145 mm 3/8"
BSP
NPT
24 mm
M6
41 mm
5.12" 6.3" 6.38" 4.13" 4.8" 0.31" 5.51" 5.31" 2.76" 5.71" 0.94" 1.61"
DF50 / DF50T
A B C D E F G H
156 mm 160 mm 167 mm 105 mm 122 mm 8 mm 146 mm 140 mm
6.14" 6.3" 6.57" 4.13" 4.8" 0.31" 5.75" 5.51"
H I J K L M N P
140 mm 70 mm
1/2" BPS NPT
NPSM
150 mm
3/8" NPSM
24 mm
M6
41 mm
5.51" 2.76" 5.91" 0.94" 1.61"
DF100
A B C D E F G H I J K L
216 mm 189 mm 227 mm 175 mm 154 mm 9 mm 184 mm 210 mm 94,51 mm
1"BSP
NPT
210 mm
3/8" NPSM
8.5" 7.44" 8.94" 6.89" 6.06" 0.35" 7.24" 8.27" 3.72" 8.27"
